Our egg tray making machine and paper making machine are famous brands in China
1. Step less adjustment, each function can be operated independently;
2. Automatic paper core loading and replacing. The logs are automatically pushed out after finishing winding, and then start winding again.
3. With high precision screwy perforation knife, makes a lower perforation noise and clearer perforating, larger adjusting scope of gear box.
4. Horizontal back-stands, pneumatic jumbo roll loading, and pneumatically wide belt paper unwinding driving, and individual web tension control unit for each jumbo roll.
5. The web can be threaded on the machine by the two jog buttons, It's more safety and easier to feed the web.
Technical Details | |
Raw material tissue max width | 1100mm/1300mm |
Finished roll diameter | Φ80~130 mm (adjustment tightness) |
Finished paper core inner diameter | Φ 28～50 mm(customized) |
Finished roll rewinding core shaft | Φ 42mm(customized) |
Raw material diameter | ≤1200 mm |
Raw material core inner diameter | φ76.2cm |
Perforation pitch | 280mm (Adjustable) |
Working Speed | 70-120 meters/Min |
Counting | Electronic counter |
Unwinding unit | 1 ply |
Pneumatic unit | 3HP air compressor min |
Drying Unit | Hot air drying |
Printing unit | Single color flexo printing |
Control System | PLC control |
Loading or Raw material | Pneumatic |
Total weight | About 3500kgs |
Dimension (L*W*H) | About 9500*2700*2000mm |
Working Power | 380V 50Hz 3Phases 26KW |
Certification | CE |
As our egg tray making machine, carton box cardboard machine, tissue paper machines exporting to more and more countries includes USA, Russia, Spain, Ukraine, Egypt, Nigeria, Saudi Arabia, India, Australia, Philippine, Mexico, Colombia, Argentina, our machines win good reputation both in China and abroad industrial paper packaging area due to good quality first class after sales service.
