Our egg tray making machine and paper making machine are famous brands in China
This machine is a slitting rewinding machine designed and manufactured according to the characteristics of synthetic thermal paper and self-adhesive paper, can slit miminum 30mm width
1. PLC controlling system make the slitter rewinder machine having an intelligent operation. Machine using three sets servo motors control keep the rewinding roll with high precision. automatic tension control system, Center and Surface Rewinding design make the rewinding roll compact and slitting surface is very smooth.
2. Slitting rewinding machine use frequency converter adjust speed, keep stable running when speed go up.
3. Automatic count meter, automatic alarm and stop when machine had fault, automatic stop when the roll reach the setting diameter or length.
4. Rewinding shaft use two pcs differential shafts structure, with an unloading tower for easy material discharge.
5. The automatic web guide system uses ultrasonic sensors to automatically adjust the unwinding position.
6.It adopts circular knife slitting, with waste edge removed automatically by air blower.
7.Unwinding adopts shaftless hydraulic loading structure, with magnetic powder taper tension control. It is fitted with 3-6 inch self-locking mechanical expanding sleeves for material clamping and side guards.
Thermal paper slitting rewinding machine popular in Europe and South America
Max mother roll width : 2000mm
Min rewinding roll width: 30mm
Max diameter mother roll: 1400mm
Max diameter winded roll: 600mm
Max mother roll weight: 1200kgs
Slitting speed: 0-300 meters/minute
Paper grammage range: 45-200 GSM
Rewinding way: Center winder
Precision: ±0.2mm
Speed regulation control: Frequency converter
Power input: 380V,50HZ,3PH, 27KW
Dimension: About 3550*4700*2035(L*W*H)
Total weight: About 6000kgs
What's app +86 18561832088, please feel free to contact with us online for our paper slitting rewinding machine's working video
As our egg tray making machine, carton box cardboard machine, tissue paper machines exporting to more and more countries includes USA, Russia, Spain, Ukraine, Egypt, Nigeria, Saudi Arabia, India, Australia, Philippine, Mexico, Colombia, Argentina, our machines win good reputation both in China and abroad industrial paper packaging area due to good quality first class after sales service.
